SOUND GENERATORMaximum Polyphony256 voicesParts16 partsTonesTones: 433 + 256 (GM2)
Drum Sets: 9 + 9 (GM2)EffectsEqualizer: 6 types
Reverb: 11 types
Chorus: 12 typesMic Effects3-Band Equalizer
Reverb: 11 types
Chorus: 12 types
Delay: 2 types
Other: 5 typesKEYBOARDKeyboard61 keys (with velocity)Touch SensitivityKey Touch: 3 types, fixed touchSPEAKER SYSTEMSpeakersSpeakers: 12 cm (4-3/4 inches) x 2
Tweeters: 3 cm (1-1/4 inch) x 2Rated Power Output10 W x 2ARRANGERStylesPreset: 300 stylesTempo30--280One Touch Setting4 settings/styleRegistration8 banks x 4 memoriesControlsSTART/STOP, INTRO/ENDING, FADE IN/OUT, FILL 1/3, FILL 2/4, CHORD, SYNCSCALE TUNINGSScale Recall12 user scale memoriesUser Scale ButtonsQuarter-tone tuning
Tuning range: -50--+50 cent
* Capable save as user setting.AUDIO PADSAudio Pads12 pads for Audio playbacker via USB flash driveData TypeMP3: 44.1 kHz, 32 kbps--320 kbps
WAV: 48 kHz/44.1 kHz/22 kHz, 16-bit linear formatBLUETOOTHBluetoothAudio: Bluetooth Ver 5.0SONGDemo Songs1 songRecorder10 songsData playbackAudio File (WAV: 48 kHz/44.1 kHz/22 kHz, 16-bit linear format, MP3: 44.1 kHz, 32 kbps--320 kbps, requires USB flash drive)CONVENIENT FUNCTIONSConvenient FunctionsMetronome (Adjustable Tempo/Beat/Volume)
Transpose (Keyboard: in semitones)
Dual
Split (Split point adjustable)
Speaker Auto Mute
Auto OffOTHERConnectorsPHONES jack: stereo 1/4-inch phone type
MIC INPUT jack: 1/4-inch TRS phone type
OUTPUT (L/MONO, R) jacks: 1/4-inch phone type
PEDAL jack: 1/4-inch phone type
USB COMPUTER port: USB B type
USB MEMORY port: USB A type
DC IN jackControllersPitch bend wheelDisplayCustom LCDPower SupplyAC adaptorPower Consumption30 W (When using the included AC adaptor)AccessoriesOwner's manual
Leaflet "USING THE UNIT SAFELY"
AC adaptor
Music restOptions (sold separately)Pedal switch: DP seriesSIZE AND WEIGHTWidthWith music rest:
1,048 mm
41-17/64 inches

Without music rest:
1,048 mm
41-17/64 inchesDepthWith music rest:
461 mm
18-5/32 inches

Without music rest:
391 mm
15-25/64 inchesHeightWith music rest:
319 mm
12-9/16 inches

Without music rest:
141 mm
5-35/64 inchesWeight (excluding AC adaptor and music rest)9.6 kg
21 lbs 3 oz
